Avirex

Click on Number to order Part

Fig.	Part Number	Description	Qty	Unit/Price	Add to Cart
1-15			1	0	+
2	827441	SPACER RING 30,5/42/2	1	11.18	+
3	832208	ROULEMENT VILEBREQUIN (PETIT)	2	98.62	+
4	830355	O-RING 49,2-1,8	2	5.45	+
5	827715	STOP SHIM 30,4/51/1	1	3.19	+
6	830748	OIL SEAL AS 30X62X7/7,5 NBR	1	37.87	+
7	827760	ENTRETOISE VILEBREQUIN 35.5/47/2	1	5.92	+
8	632741	USE 632743	2	174.14	+
9	250165	O-RING 64-2	2	5.26	+
10	830293	Entretoise vilebrequin 532/582	1	52.33	+
11	830370	O-RING 63-2,5	1	6.84	+
12	831950	OIL SEAL AS 35X72X7/8,5 NBR	1	40.58	+
13-14	832320	CAGEL. NEEDLE BEARING 18X22X23	2	58.86	+
14	827465	THRUST WASHER 18/21,7/2,5	4	24.38	+
15	246055	WOODRUFF KEY 3X3,7 DIN 6888	1	3.46	+
16	945759	LOCK WASHER 22	1	1.61	+
17	842239	HEX. NUT M22X1,5	1	12.5	+
18-20	888590	PISTON ASSY. 75,94/75,95 MM	2ab	342.32	+
18-20	888591	PISTON ASSY. 76,19/76,20 MM	2ac	335.75	+
18-20	888592	PISTON ASSY. 76,44/76,45 MM	2ad	335.75	+
19e	215200	RECTANGULAR RING 76,00 MM	2e	61.62	+
19f	215201	RECTANGULAR RING 76,25 MM	2f	69.01	+
19g	215202	RECTANGULAR RING 76,5 MM	2g	69.01	+
20e	915820	SEMI-TRAPEZ RING 76,0 MM	2e	100.7	+
20f	915821	SEMI-TRAPEZ RING 76,25 MM	2f	102.9	+
20g	915822	SEMI-TRAPEZ RING 76,5 MM	2g	102.9	+
21	916136	PISTON PIN 18X11X53,7	2	49.72	+
22	845540	MONOHOOK CIRCLIP 18	4hi	1.87	+
